DC Axial-Flow Fan
★General Specification(一般规格）
☆Material:
Frame And Lmpeller:Thermal Plastic UL 94V-0
☆Lead Wires:UL Type
RED Wire Positive(+)
BLACK Wire Negative(-)
☆Insulation Resistance:10MΩ Or Over With a
DC250V Megger
☆Dielectric Withstand Voltage:AC500V 1S
☆Allowable Ambient Temperature Range:
-10℃～+70℃(Operation)
-40℃～+70℃(Storage)
| ★Dimensions Drawing（外观图） | ★Characteristic Curves（特性曲线） |
 |
 |
| ★Specifications（规格） | ||||||||||
| Model | Bearing | Rated | Operation | Current | Input | Speed | Air Flow | Static | Niose | Weight |
| System | Voltage | Voltage | power | Pressure | Level | |||||
| (V) | (V) | (A) | (W) | (RPM) | (CFM) | (mm-H2O) | (dB-A) | (g) | ||
| (型号) | (培林) | (电压) | (电压范围) | (电流) | (功率) | (转速) | (风量) | (静压) | (噪音) | (重量) |
| YD054010HSL | 5 | 4.5～5.5 | 0.24 | 1.20 | 6000 | 6.40 | 3.31 | 26.26 | 17 | |
| YD054010MSL | Sleeve | 0.18 | 0.90 | 5400 | 5.62 | 2.91 | 24.87 | 17 | ||
| YD054010LSL | 0.12 | 0.60 | 4200 | 4.48 | 2.32 | 21.13 | 17 | |||
| YD054010HBL | 0.24 | 1.20 | 6000 | 6.40 | 3.31 | 26.26 | 17 | |||
| YD054010MBL | Ball | 0.18 | 0.90 | 5400 | 5.62 | 2.91 | 24.87 | 17 | ||
| YD054010LBL | 0.12 | 0.60 | 4200 | 4.48 | 2.32 | 21.13 | 17 | |||
| YD124010HSL | 12 | 10.8～13.2 | 0.10 | 1.20 | 6000 | 6.40 | 3.31 | 26.26 | 17 | |
| YD124010MSL | Sleeve | 0.08 | 0.96 | 5400 | 5.62 | 2.91 | 24.87 | 17 | ||
| YD124010LSL | 0.06 | 0.72 | 4200 | 4.48 | 2.32 | 21.13 | 17 | |||
| YD124010HBL | 0.10 | 1.20 | 6000 | 6.40 | 3.31 | 26.26 | 17 | |||
| YD124010MBL | Ball | 0.08 | 0.96 | 5400 | 5.62 | 2.91 | 24.87 | 17 | ||
| YD124010LBL | 0.06 | 0.72 | 4200 | 4.48 | 2.32 | 21.13 | 17 | |||
